NTPsec

A-ntpsec-6-hour-stats

Report generated: Sat Mar 21 06:05:51 2026 UTC
Start Time: Sat Mar 21 00:05:51 2026 UTC
End Time: Sat Mar 21 06:05:51 2026 UTC
Report published: Fri Mar 20 11:06:14 PM 2026 PDT
Report Period: 0.2 days

Local Clock Time/Frequency Offsets

local offset plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local Clock Time Offset -3.035 -1.832 -1.223 0.169 1.170 1.542 2.226 2.393 3.374 0.723 0.100 µs -3.752 10.24
Local Clock Frequency Offset -226.273 -223.663 -215.286 -112.045 -88.333 -87.570 -87.051 126.953 136.093 42.668 -128.365 ppb -77.32 371.3

The time and frequency offsets between the ntpd calculated time and the local system clock. Showing frequency offset (red, in parts per million, scale on right) and the time offset (blue, in μs, scale on left). Quick changes in time offset will lead to larger frequency offsets.

These are fields 3 (time) and 4 (frequency) from the loopstats log file.



Local RMS Time Jitter

local jitter plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local RMS Time Jitter 0.453 0.540 0.618 0.920 1.280 1.464 1.680 0.662 0.924 0.203 0.930 µs 57.22 250.9

The RMS Jitter of the local clock offset. In other words, how fast the local clock offset is changing.

Lower is better. An ideal system would be a horizontal line at 0μs.

RMS jitter is field 5 in the loopstats log file.



Local RMS Frequency Jitter

local stability plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local RMS Frequency Jitter 187.000 218.000 247.000 347.000 466.000 521.000 626.000 219.000 303.000 67.085 349.819 10e-12 87.88 431.5

The RMS Frequency Jitter (aka wander) of the local clock's frequency. In other words, how fast the local clock changes frequency.

Lower is better. An ideal clock would be a horizontal line at 0ppm.

RMS Frequency Jitter is field 6 in the loopstats log file.



Local Clock Time Offset Histogram

local offset histogram plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local Clock Offset -3.035 -1.832 -1.223 0.169 1.170 1.542 2.226 2.393 3.374 0.723 0.100 µs -3.752 10.24

The clock offsets of the local clock as a histogram.

The Local Clock Offset is field 3 from the loopstats log file.



Local Temperatures

local temps plot

Local temperatures. These will be site-specific depending upon what temperature sensors you collect data from. Temperature changes affect the local clock crystal frequency and stability. The math of how temperature changes frequency is complex, and also depends on crystal aging. So there is no easy way to correct for it in software. This is the single most important component of frequency drift.

The Local Temperatures are from field 3 from the tempstats log file.



Local Frequency/Temp

local freq temps plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local Clock Frequency Offset -226.273 -223.663 -215.286 -112.045 -88.333 -87.570 -87.051 126.953 136.093 42.668 -128.365 ppb -77.32 371.3
Temp ZONE0 46.160 46.160 46.698 47.774 48.312 48.312 48.850 1.614 2.152 0.542 47.681 °C

The frequency offsets and temperatures. Showing frequency offset (red, in parts per million, scale on right) and the temperatures.

These are field 4 (frequency) from the loopstats log file, and field 3 from the tempstats log file.



Local GPS

local gps plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
nSats 7.000 7.000 8.000 9.000 12.000 13.000 13.000 4.000 6.000 1.325 9.518 nSat 255.5 1710
TDOP 0.480 0.490 0.530 0.870 1.200 1.340 1.630 0.670 0.850 0.203 0.881 47.89 198.7

Local GPS. The Time Dilution of Precision (TDOP) is plotted in blue. The number of visible satellites (nSat) is plotted in red.

TDOP is field 3, and nSats is field 4, from the gpsd log file. The gpsd log file is created by the ntploggps program.

TDOP is a dimensionless error factor. Smaller numbers are better. TDOP ranges from 1 (ideal), 2 to 5 (good), to greater than 20 (poor). Some GNSS receivers report TDOP less than one which is theoretically impossible.



Server Offsets

peer offsets plot

The offset of all refclocks and servers. This can be useful to see if offset changes are happening in a single clock or all clocks together.

Clock Offset is field 5 in the peerstats log file.



Server Offset 157.131.224.9

peer offset 157.131.224.9 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 157.131.224.9 -12.473 -12.473 -10.786 2.787 4.926 6.339 6.339 15.712 18.812 4.653 0.687 ms -4.755 14.67

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 173.11.101.155

peer offset 173.11.101.155 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 173.11.101.155 -5.395 -5.395 -4.112 -0.490 3.979 6.140 6.140 8.090 11.535 2.542 -0.207 ms -4.291 9.943

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 192.12.19.20

peer offset 192.12.19.20 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 192.12.19.20 -0.947 -0.947 -0.185 1.603 4.040 4.515 4.515 4.225 5.462 1.174 1.751 ms 1.927 5.103

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 2606:4700:f1::1 (time.cloudflare.com)

peer offset 2606:4700:f1::1 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 2606:4700:f1::1 (time.cloudflare.com) 1.134 1.134 1.622 3.056 4.729 5.574 5.574 3.107 4.439 1.039 3.226 ms 15.73 48.9

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 2606:4700:f1::123 (time.cloudflare.com)

peer offset 2606:4700:f1::123 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 2606:4700:f1::123 (time.cloudflare.com) 1.108 1.108 1.108 1.108 1.108 1.108 1.108 0.000 0.000 0.000 1.108 ms nan nan

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 2607:5300:205:200::9bc0 (fjord.txryan.com)

peer offset 2607:5300:205:200::9bc0 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 2607:5300:205:200::9bc0 (fjord.txryan.com) 3.641 3.641 4.065 5.734 7.655 11.098 11.098 3.590 7.457 1.192 5.959 ms 76.95 373.7

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 2607:f140:ffff:8000:0:8006:0:a (ntp1.net.berkeley.edu)

peer offset 2607:f140:ffff:8000:0:8006:0:a plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 2607:f140:ffff:8000:0:8006:0:a (ntp1.net.berkeley.edu) 0.525 0.525 1.706 2.744 4.742 4.925 4.925 3.036 4.400 0.920 2.976 ms 18.33 61.95

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 50.116.42.84

peer offset 50.116.42.84 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 50.116.42.84 -0.098 -0.098 0.651 1.908 4.154 4.459 4.459 3.502 4.557 1.108 2.276 ms 4.6 11.08

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 52.10.183.132

peer offset 52.10.183.132 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 52.10.183.132 -1.032 -1.032 0.737 2.561 4.271 10.381 10.381 3.535 11.413 1.423 2.789 ms 5.262 23.49

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 66.220.9.122

peer offset 66.220.9.122 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 66.220.9.122 -1.274 -1.274 1.500 2.754 5.305 6.551 6.551 3.805 7.825 1.181 2.899 ms 7.798 24.77

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset SHM(0)

peer offset SHM(0) plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset SHM(0) -133.957 -133.930 -133.561 -129.689 -127.715 -127.014 -126.619 5.847 6.915 1.682 -130.019 ms -4.803e+05 3.763e+07

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset SHM(1)

peer offset SHM(1) plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset SHM(1) -3.036 -1.833 -1.224 0.170 1.171 1.543 2.227 2.395 3.376 0.724 0.100 µs -3.751 10.23

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Jitters

peer jitters plot

The RMS Jitter of all refclocks and servers. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 157.131.224.9

peer jitter 157.131.224.9 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 157.131.224.9 1.040 1.040 1.455 4.101 13.484 18.120 18.120 12.029 17.081 4.006 5.525 ms 2.345 6.453

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 173.11.101.155

peer jitter 173.11.101.155 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 173.11.101.155 1.828 1.828 2.234 6.778 59.047 159.254 159.254 56.813 157.426 26.876 13.269 ms 3.068 17.17

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 192.12.19.20

peer jitter 192.12.19.20 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 192.12.19.20 1.025 1.025 1.119 3.269 14.663 85.651 85.651 13.544 84.627 13.729 6.502 ms 3.323 19.75

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 2606:4700:f1::1 (time.cloudflare.com)

peer jitter 2606:4700:f1::1 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 2606:4700:f1::1 (time.cloudflare.com) 0.633 0.633 1.123 3.703 6.329 10.175 10.175 5.206 9.543 1.722 3.639 ms 5.58 17.73

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 2606:4700:f1::123 (time.cloudflare.com)

peer jitter 2606:4700:f1::123 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 2606:4700:f1::123 (time.cloudflare.com) 4.027 4.027 4.027 4.027 4.027 4.027 4.027 0.000 0.000 0.000 4.027 ms nan nan

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 2607:5300:205:200::9bc0 (fjord.txryan.com)

peer jitter 2607:5300:205:200::9bc0 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 2607:5300:205:200::9bc0 (fjord.txryan.com) 1.072 1.072 1.606 3.621 11.906 19.371 19.371 10.300 18.300 3.524 4.982 ms 2.847 8.96

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 2607:f140:ffff:8000:0:8006:0:a (ntp1.net.berkeley.edu)

peer jitter 2607:f140:ffff:8000:0:8006:0:a plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 2607:f140:ffff:8000:0:8006:0:a (ntp1.net.berkeley.edu) 1.359 1.359 1.862 3.790 19.936 20.421 20.421 18.074 19.062 4.722 5.453 ms 2.579 7.926

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 50.116.42.84

peer jitter 50.116.42.84 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 50.116.42.84 1.573 1.573 2.291 3.932 17.251 51.990 51.990 14.960 50.418 8.639 6.483 ms 3.572 18.36

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 52.10.183.132

peer jitter 52.10.183.132 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 52.10.183.132 1.102 1.102 1.315 3.477 13.675 18.145 18.145 12.360 17.043 3.856 4.968 ms 2.426 7.221

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 66.220.9.122

peer jitter 66.220.9.122 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 66.220.9.122 0.851 0.851 1.490 4.977 12.057 34.771 34.771 10.567 33.920 4.485 5.339 ms 4.589 29.23

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter SHM(0)

peer jitter SHM(0) plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter SHM(0) 0.038 0.057 0.106 0.438 1.367 2.074 2.468 1.261 2.018 0.395 0.541 ms 3.091 11.72

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter SHM(1)

peer jitter SHM(1) plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter SHM(1) 0.204 0.320 0.458 0.889 1.701 2.186 3.116 1.243 1.866 0.396 0.959 µs 8.299 28.05

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Summary


Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local Clock Frequency Offset -226.273 -223.663 -215.286 -112.045 -88.333 -87.570 -87.051 126.953 136.093 42.668 -128.365 ppb -77.32 371.3
Local Clock Time Offset -3.035 -1.832 -1.223 0.169 1.170 1.542 2.226 2.393 3.374 0.723 0.100 µs -3.752 10.24
Local RMS Frequency Jitter 187.000 218.000 247.000 347.000 466.000 521.000 626.000 219.000 303.000 67.085 349.819 10e-12 87.88 431.5
Local RMS Time Jitter 0.453 0.540 0.618 0.920 1.280 1.464 1.680 0.662 0.924 0.203 0.930 µs 57.22 250.9
Server Jitter 157.131.224.9 1.040 1.040 1.455 4.101 13.484 18.120 18.120 12.029 17.081 4.006 5.525 ms 2.345 6.453
Server Jitter 173.11.101.155 1.828 1.828 2.234 6.778 59.047 159.254 159.254 56.813 157.426 26.876 13.269 ms 3.068 17.17
Server Jitter 192.12.19.20 1.025 1.025 1.119 3.269 14.663 85.651 85.651 13.544 84.627 13.729 6.502 ms 3.323 19.75
Server Jitter 2606:4700:f1::1 (time.cloudflare.com) 0.633 0.633 1.123 3.703 6.329 10.175 10.175 5.206 9.543 1.722 3.639 ms 5.58 17.73
Server Jitter 2606:4700:f1::123 (time.cloudflare.com) 4.027 4.027 4.027 4.027 4.027 4.027 4.027 0.000 0.000 0.000 4.027 ms nan nan
Server Jitter 2607:5300:205:200::9bc0 (fjord.txryan.com) 1.072 1.072 1.606 3.621 11.906 19.371 19.371 10.300 18.300 3.524 4.982 ms 2.847 8.96
Server Jitter 2607:f140:ffff:8000:0:8006:0:a (ntp1.net.berkeley.edu) 1.359 1.359 1.862 3.790 19.936 20.421 20.421 18.074 19.062 4.722 5.453 ms 2.579 7.926
Server Jitter 50.116.42.84 1.573 1.573 2.291 3.932 17.251 51.990 51.990 14.960 50.418 8.639 6.483 ms 3.572 18.36
Server Jitter 52.10.183.132 1.102 1.102 1.315 3.477 13.675 18.145 18.145 12.360 17.043 3.856 4.968 ms 2.426 7.221
Server Jitter 66.220.9.122 0.851 0.851 1.490 4.977 12.057 34.771 34.771 10.567 33.920 4.485 5.339 ms 4.589 29.23
Server Jitter SHM(0) 0.038 0.057 0.106 0.438 1.367 2.074 2.468 1.261 2.018 0.395 0.541 ms 3.091 11.72
Server Jitter SHM(1) 0.204 0.320 0.458 0.889 1.701 2.186 3.116 1.243 1.866 0.396 0.959 µs 8.299 28.05
Server Offset 157.131.224.9 -12.473 -12.473 -10.786 2.787 4.926 6.339 6.339 15.712 18.812 4.653 0.687 ms -4.755 14.67
Server Offset 173.11.101.155 -5.395 -5.395 -4.112 -0.490 3.979 6.140 6.140 8.090 11.535 2.542 -0.207 ms -4.291 9.943
Server Offset 192.12.19.20 -0.947 -0.947 -0.185 1.603 4.040 4.515 4.515 4.225 5.462 1.174 1.751 ms 1.927 5.103
Server Offset 2606:4700:f1::1 (time.cloudflare.com) 1.134 1.134 1.622 3.056 4.729 5.574 5.574 3.107 4.439 1.039 3.226 ms 15.73 48.9
Server Offset 2606:4700:f1::123 (time.cloudflare.com) 1.108 1.108 1.108 1.108 1.108 1.108 1.108 0.000 0.000 0.000 1.108 ms nan nan
Server Offset 2607:5300:205:200::9bc0 (fjord.txryan.com) 3.641 3.641 4.065 5.734 7.655 11.098 11.098 3.590 7.457 1.192 5.959 ms 76.95 373.7
Server Offset 2607:f140:ffff:8000:0:8006:0:a (ntp1.net.berkeley.edu) 0.525 0.525 1.706 2.744 4.742 4.925 4.925 3.036 4.400 0.920 2.976 ms 18.33 61.95
Server Offset 50.116.42.84 -0.098 -0.098 0.651 1.908 4.154 4.459 4.459 3.502 4.557 1.108 2.276 ms 4.6 11.08
Server Offset 52.10.183.132 -1.032 -1.032 0.737 2.561 4.271 10.381 10.381 3.535 11.413 1.423 2.789 ms 5.262 23.49
Server Offset 66.220.9.122 -1.274 -1.274 1.500 2.754 5.305 6.551 6.551 3.805 7.825 1.181 2.899 ms 7.798 24.77
Server Offset SHM(0) -133.957 -133.930 -133.561 -129.689 -127.715 -127.014 -126.619 5.847 6.915 1.682 -130.019 ms -4.803e+05 3.763e+07
Server Offset SHM(1) -3.036 -1.833 -1.224 0.170 1.171 1.543 2.227 2.395 3.376 0.724 0.100 µs -3.751 10.23
TDOP 0.480 0.490 0.530 0.870 1.200 1.340 1.630 0.670 0.850 0.203 0.881 47.89 198.7
Temp ZONE0 46.160 46.160 46.698 47.774 48.312 48.312 48.850 1.614 2.152 0.542 47.681 °C
nSats 7.000 7.000 8.000 9.000 12.000 13.000 13.000 4.000 6.000 1.325 9.518 nSat 255.5 1710
Summary as CSV file


Glossary:

frequency offset:
The difference between the ntpd calculated frequency and the local system clock frequency (usually in parts per million, ppm)
jitter, dispersion:
The short term change in a value. NTP measures Local Time Jitter, Refclock Jitter, and Server Jitter in seconds. Local Frequency Jitter is in ppm or ppb.
kurtosis, Kurt:
The kurtosis of a random variable X is the fourth standardized moment and is a dimension-less ratio. ntpviz uses the Pearson's moment coefficient of kurtosis. A normal distribution has a kurtosis of three. NIST describes a kurtosis over three as "heavy tailed" and one under three as "light tailed".
ms, millisecond:
One thousandth of a second = 0.001 seconds, 1e-3 seconds
mu, mean:
The arithmetic mean: the sum of all the values divided by the number of values. The formula for mu is: "mu = (∑xi) / N". Where xi denotes the data points and N is the number of data points.
ns, nanosecond:
One billionth of a second, also one thousandth of a microsecond, 0.000000001 seconds and 1e-9 seconds.
percentile:
The value below which a given percentage of values fall.
ppb, parts per billion:
Ratio between two values. These following are all the same: 1 ppb, one in one billion, 1/1,000,000,000, 0.000,000,001, 1e-9 and 0.000,000,1%
ppm, parts per million:
Ratio between two values. These following are all the same: 1 ppm, one in one million, 1/1,000,000, 0.000,001, and 0.000,1%
‰, parts per thousand:
Ratio between two values. These following are all the same: 1 ‰. one in one thousand, 1/1,000, 0.001, and 0.1%
refclock:
Reference clock, a local GPS module or other local source of time.
remote clock:
Any clock reached over the network, LAN or WAN. Also called a peer or server.
time offset:
The difference between the ntpd calculated time and the local system clock's time. Also called phase offset.
σ, sigma:
Sigma denotes the standard deviation (SD) and is centered on the arithmetic mean of the data set. The SD is simply the square root of the variance of the data set. Two sigma is simply twice the standard deviation. Three sigma is three times sigma. Smaller is better.
The formula for sigma is: "σ = √[ ∑(xi-mu)^2 / N ]". Where xi denotes the data points and N is the number of data points.
skewness, Skew:
The skewness of a random variable X is the third standardized moment and is a dimension-less ratio. ntpviz uses the Pearson's moment coefficient of skewness. Wikipedia describes it best: "The qualitative interpretation of the skew is complicated and unintuitive."
A normal distribution has a skewness of zero.
upstream clock:
Any server or reference clock used as a source of time.
µs, us, microsecond:
One millionth of a second, also one thousandth of a millisecond, 0.000,001 seconds, and 1e-6 seconds.



This page autogenerated by ntpviz, part of the NTPsec project
html 5    Valid CSS!
