NTPsec

A-ntpsec-24-hour-stats

Report generated: Sat Jul 27 06:06:36 2024 UTC
Start Time: Fri Jul 26 06:06:35 2024 UTC
End Time: Sat Jul 27 06:06:35 2024 UTC
Report published: Fri Jul 26 11:06:44 PM 2024 PDT
Report Period: 1.0 days

Local Clock Time/Frequency Offsets

local offset plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local Clock Time Offset -3.127 -1.714 -1.215 0.029 0.991 1.335 2.071 2.206 3.049 0.668 -0.022 µs -4.583 12.23
Local Clock Frequency Offset -591.904 -590.622 -588.242 -395.355 -247.650 -206.039 -198.807 340.592 384.583 116.903 -410.174 ppb -105.3 539

The time and frequency offsets between the ntpd calculated time and the local system clock. Showing frequency offset (red, in parts per million, scale on right) and the time offset (blue, in μs, scale on left). Quick changes in time offset will lead to larger frequency offsets.

These are fields 3 (time) and 4 (frequency) from the loopstats log file.



Local RMS Time Jitter

local jitter plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local RMS Time Jitter 0.380 0.481 0.566 0.827 1.181 1.331 1.686 0.615 0.850 0.187 0.845 µs 54.88 238.7

The RMS Jitter of the local clock offset. In other words, how fast the local clock offset is changing.

Lower is better. An ideal system would be a horizontal line at 0μs.

RMS jitter is field 5 in the loopstats log file.



Local RMS Frequency Jitter

local stability plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local RMS Frequency Jitter 156.000 191.000 220.000 316.000 438.000 499.000 603.000 218.000 308.000 65.845 320.233 10e-12 69.74 323.1

The RMS Frequency Jitter (aka wander) of the local clock's frequency. In other words, how fast the local clock changes frequency.

Lower is better. An ideal clock would be a horizontal line at 0ppm.

RMS Frequency Jitter is field 6 in the loopstats log file.



Local Clock Time Offset Histogram

local offset histogram plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local Clock Offset -3.127 -1.714 -1.215 0.029 0.991 1.335 2.071 2.206 3.049 0.668 -0.022 µs -4.583 12.23

The clock offsets of the local clock as a histogram.

The Local Clock Offset is field 3 from the loopstats log file.



Local Temperatures

local temps plot

Local temperatures. These will be site-specific depending upon what temperature sensors you collect data from. Temperature changes affect the local clock crystal frequency and stability. The math of how temperature changes frequency is complex, and also depends on crystal aging. So there is no easy way to correct for it in software. This is the single most important component of frequency drift.

The Local Temperatures are from field 3 from the tempstats log file.



Local Frequency/Temp

local freq temps plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local Clock Frequency Offset -591.904 -590.622 -588.242 -395.355 -247.650 -206.039 -198.807 340.592 384.583 116.903 -410.174 ppb -105.3 539
Temp ZONE0 43.470 43.470 44.008 45.622 47.236 47.236 47.774 3.228 3.766 1.067 45.452 °C

The frequency offsets and temperatures. Showing frequency offset (red, in parts per million, scale on right) and the temperatures.

These are field 4 (frequency) from the loopstats log file, and field 3 from the tempstats log file.



Local GPS

local gps plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
nSats 6.000 8.000 8.000 10.000 12.000 13.000 14.000 4.000 5.000 1.154 9.733 nSat 434 3408
TDOP 0.470 0.520 0.560 0.810 1.210 1.380 3.230 0.650 0.860 0.215 0.850 36.03 158.4

Local GPS. The Time Dilution of Precision (TDOP) is plotted in blue. The number of visible satellites (nSat) is plotted in red.

TDOP is field 3, and nSats is field 4, from the gpsd log file. The gpsd log file is created by the ntploggps program.

TDOP is a dimensionless error factor. Smaller numbers are better. TDOP ranges from 1 (ideal), 2 to 5 (good), to greater than 20 (poor). Some GNSS receivers report TDOP less than one which is theoretically impossible.



Server Offsets

peer offsets plot

The offset of all refclocks and servers. This can be useful to see if offset changes are happening in a single clock or all clocks together.

Clock Offset is field 5 in the peerstats log file.



Server Offset 162.159.200.1

peer offset 162.159.200.1 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 162.159.200.1 -0.438 3.036 3.725 5.186 8.919 11.469 15.569 5.195 8.433 1.728 5.615 ms 20.02 83.37

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 162.159.200.123

peer offset 162.159.200.123 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 162.159.200.123 1.238 1.238 4.292 4.726 7.762 9.270 9.270 3.470 8.032 1.108 4.939 ms 53.22 243.2

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 169.229.128.134

peer offset 169.229.128.134 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 169.229.128.134 -1.637 -0.843 0.907 2.725 5.954 7.899 8.860 5.046 8.742 1.590 2.897 ms 3.991 12.66

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 173.11.101.155

peer offset 173.11.101.155 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 173.11.101.155 -3.929 -2.800 -1.910 1.126 4.891 8.207 10.220 6.802 11.007 2.046 1.282 ms -0.4723 4.543

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 192.12.19.20

peer offset 192.12.19.20 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 192.12.19.20 0.933 1.415 2.102 3.975 7.766 9.026 10.521 5.663 7.610 1.599 4.227 ms 10.5 35.51

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 5.161.184.148

peer offset 5.161.184.148 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 5.161.184.148 -11.607 -1.025 1.403 2.810 5.901 9.058 15.272 4.498 10.083 1.811 3.180 ms 2.353 27.62

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 50.116.42.84

peer offset 50.116.42.84 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 50.116.42.84 1.956 4.329 4.930 6.392 10.199 11.941 16.277 5.269 7.612 1.628 6.851 ms 44.38 197.9

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 52.10.183.132

peer offset 52.10.183.132 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 52.10.183.132 2.062 2.511 3.460 4.972 8.929 10.208 10.625 5.469 7.697 1.580 5.349 ms 21.94 82.49

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 64.142.122.36

peer offset 64.142.122.36 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 64.142.122.36 -0.818 -0.473 0.893 2.885 6.564 8.078 8.146 5.671 8.551 1.718 2.937 ms 3.425 9.681

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 66.220.9.122

peer offset 66.220.9.122 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 66.220.9.122 0.206 0.621 1.750 3.473 7.037 8.998 9.971 5.287 8.377 1.645 3.687 ms 6.856 22.62

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset SHM(0)

peer offset SHM(0) plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset SHM(0) -135.736 -134.699 -133.048 -130.301 -128.263 -127.549 -126.543 4.785 7.150 1.412 -130.461 ms -8.155e+05 7.62e+07

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset SHM(1)

peer offset SHM(1) plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset SHM(1) -3.128 -1.715 -1.216 0.030 0.992 1.336 2.072 2.208 3.051 0.669 -0.022 µs -4.581 12.22

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Jitters

peer jitters plot

The RMS Jitter of all refclocks and servers. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 162.159.200.1

peer jitter 162.159.200.1 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 162.159.200.1 0.216 0.347 0.878 5.905 18.049 22.589 31.629 17.172 22.242 6.017 7.527 ms 1.569 4.288

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 162.159.200.123

peer jitter 162.159.200.123 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 162.159.200.123 0.509 0.509 0.682 2.379 16.602 25.304 25.304 15.919 24.795 5.845 5.400 ms 1.198 3.965

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 169.229.128.134

peer jitter 169.229.128.134 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 169.229.128.134 0.401 0.561 0.975 4.529 18.751 26.625 62.700 17.776 26.064 7.439 7.330 ms 2.961 20.21

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 173.11.101.155

peer jitter 173.11.101.155 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 173.11.101.155 0.830 0.895 1.596 5.189 18.792 41.766 42.480 17.196 40.871 7.200 8.133 ms 2.359 10.19

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 192.12.19.20

peer jitter 192.12.19.20 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 192.12.19.20 0.474 0.726 0.994 5.202 17.998 22.514 24.317 17.004 21.789 6.072 7.771 ms 1.454 3.22

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 5.161.184.148

peer jitter 5.161.184.148 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 5.161.184.148 0.121 0.263 0.821 4.390 19.392 23.826 24.678 18.571 23.563 6.211 7.009 ms 1.298 3.23

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 50.116.42.84

peer jitter 50.116.42.84 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 50.116.42.84 0.477 0.504 0.806 4.789 17.614 22.643 26.764 16.808 22.139 5.950 7.032 ms 1.432 3.596

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 52.10.183.132

peer jitter 52.10.183.132 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 52.10.183.132 0.536 0.780 0.983 5.301 17.343 19.465 22.930 16.360 18.685 5.277 6.665 ms 1.557 3.742

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 64.142.122.36

peer jitter 64.142.122.36 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 64.142.122.36 0.546 0.659 1.188 5.618 24.481 39.412 48.665 23.293 38.753 8.444 9.006 ms 1.552 5.974

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 66.220.9.122

peer jitter 66.220.9.122 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 66.220.9.122 0.178 0.409 1.017 5.560 18.303 26.500 53.921 17.286 26.091 6.855 7.607 ms 2.726 16.13

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter SHM(0)

peer jitter SHM(0) plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter SHM(0) 0.027 0.078 0.117 0.313 0.925 1.241 2.506 0.808 1.163 0.263 0.393 ms 3.057 9.937

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter SHM(1)

peer jitter SHM(1) plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter SHM(1) 0.156 0.307 0.413 0.799 1.542 1.979 3.003 1.129 1.672 0.357 0.868 µs 8.325 27.59

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Summary


Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local Clock Frequency Offset -591.904 -590.622 -588.242 -395.355 -247.650 -206.039 -198.807 340.592 384.583 116.903 -410.174 ppb -105.3 539
Local Clock Time Offset -3.127 -1.714 -1.215 0.029 0.991 1.335 2.071 2.206 3.049 0.668 -0.022 µs -4.583 12.23
Local RMS Frequency Jitter 156.000 191.000 220.000 316.000 438.000 499.000 603.000 218.000 308.000 65.845 320.233 10e-12 69.74 323.1
Local RMS Time Jitter 0.380 0.481 0.566 0.827 1.181 1.331 1.686 0.615 0.850 0.187 0.845 µs 54.88 238.7
Server Jitter 162.159.200.1 0.216 0.347 0.878 5.905 18.049 22.589 31.629 17.172 22.242 6.017 7.527 ms 1.569 4.288
Server Jitter 162.159.200.123 0.509 0.509 0.682 2.379 16.602 25.304 25.304 15.919 24.795 5.845 5.400 ms 1.198 3.965
Server Jitter 169.229.128.134 0.401 0.561 0.975 4.529 18.751 26.625 62.700 17.776 26.064 7.439 7.330 ms 2.961 20.21
Server Jitter 173.11.101.155 0.830 0.895 1.596 5.189 18.792 41.766 42.480 17.196 40.871 7.200 8.133 ms 2.359 10.19
Server Jitter 192.12.19.20 0.474 0.726 0.994 5.202 17.998 22.514 24.317 17.004 21.789 6.072 7.771 ms 1.454 3.22
Server Jitter 5.161.184.148 0.121 0.263 0.821 4.390 19.392 23.826 24.678 18.571 23.563 6.211 7.009 ms 1.298 3.23
Server Jitter 50.116.42.84 0.477 0.504 0.806 4.789 17.614 22.643 26.764 16.808 22.139 5.950 7.032 ms 1.432 3.596
Server Jitter 52.10.183.132 0.536 0.780 0.983 5.301 17.343 19.465 22.930 16.360 18.685 5.277 6.665 ms 1.557 3.742
Server Jitter 64.142.122.36 0.546 0.659 1.188 5.618 24.481 39.412 48.665 23.293 38.753 8.444 9.006 ms 1.552 5.974
Server Jitter 66.220.9.122 0.178 0.409 1.017 5.560 18.303 26.500 53.921 17.286 26.091 6.855 7.607 ms 2.726 16.13
Server Jitter SHM(0) 0.027 0.078 0.117 0.313 0.925 1.241 2.506 0.808 1.163 0.263 0.393 ms 3.057 9.937
Server Jitter SHM(1) 0.156 0.307 0.413 0.799 1.542 1.979 3.003 1.129 1.672 0.357 0.868 µs 8.325 27.59
Server Offset 162.159.200.1 -0.438 3.036 3.725 5.186 8.919 11.469 15.569 5.195 8.433 1.728 5.615 ms 20.02 83.37
Server Offset 162.159.200.123 1.238 1.238 4.292 4.726 7.762 9.270 9.270 3.470 8.032 1.108 4.939 ms 53.22 243.2
Server Offset 169.229.128.134 -1.637 -0.843 0.907 2.725 5.954 7.899 8.860 5.046 8.742 1.590 2.897 ms 3.991 12.66
Server Offset 173.11.101.155 -3.929 -2.800 -1.910 1.126 4.891 8.207 10.220 6.802 11.007 2.046 1.282 ms -0.4723 4.543
Server Offset 192.12.19.20 0.933 1.415 2.102 3.975 7.766 9.026 10.521 5.663 7.610 1.599 4.227 ms 10.5 35.51
Server Offset 5.161.184.148 -11.607 -1.025 1.403 2.810 5.901 9.058 15.272 4.498 10.083 1.811 3.180 ms 2.353 27.62
Server Offset 50.116.42.84 1.956 4.329 4.930 6.392 10.199 11.941 16.277 5.269 7.612 1.628 6.851 ms 44.38 197.9
Server Offset 52.10.183.132 2.062 2.511 3.460 4.972 8.929 10.208 10.625 5.469 7.697 1.580 5.349 ms 21.94 82.49
Server Offset 64.142.122.36 -0.818 -0.473 0.893 2.885 6.564 8.078 8.146 5.671 8.551 1.718 2.937 ms 3.425 9.681
Server Offset 66.220.9.122 0.206 0.621 1.750 3.473 7.037 8.998 9.971 5.287 8.377 1.645 3.687 ms 6.856 22.62
Server Offset SHM(0) -135.736 -134.699 -133.048 -130.301 -128.263 -127.549 -126.543 4.785 7.150 1.412 -130.461 ms -8.155e+05 7.62e+07
Server Offset SHM(1) -3.128 -1.715 -1.216 0.030 0.992 1.336 2.072 2.208 3.051 0.669 -0.022 µs -4.581 12.22
TDOP 0.470 0.520 0.560 0.810 1.210 1.380 3.230 0.650 0.860 0.215 0.850 36.03 158.4
Temp ZONE0 43.470 43.470 44.008 45.622 47.236 47.236 47.774 3.228 3.766 1.067 45.452 °C
nSats 6.000 8.000 8.000 10.000 12.000 13.000 14.000 4.000 5.000 1.154 9.733 nSat 434 3408
Summary as CSV file


Glossary:

frequency offset:
The difference between the ntpd calculated frequency and the local system clock frequency (usually in parts per million, ppm)
jitter, dispersion:
The short term change in a value. NTP measures Local Time Jitter, Refclock Jitter, and Server Jitter in seconds. Local Frequency Jitter is in ppm or ppb.
kurtosis, Kurt:
The kurtosis of a random variable X is the fourth standardized moment and is a dimension-less ratio. ntpviz uses the Pearson's moment coefficient of kurtosis. A normal distribution has a kurtosis of three. NIST describes a kurtosis over three as "heavy tailed" and one under three as "light tailed".
ms, millisecond:
One thousandth of a second = 0.001 seconds, 1e-3 seconds
mu, mean:
The arithmetic mean: the sum of all the values divided by the number of values. The formula for mu is: "mu = (∑xi) / N". Where xi denotes the data points and N is the number of data points.
ns, nanosecond:
One billionth of a second, also one thousandth of a microsecond, 0.000000001 seconds and 1e-9 seconds.
percentile:
The value below which a given percentage of values fall.
ppb, parts per billion:
Ratio between two values. These following are all the same: 1 ppb, one in one billion, 1/1,000,000,000, 0.000,000,001, 1e-9 and 0.000,000,1%
ppm, parts per million:
Ratio between two values. These following are all the same: 1 ppm, one in one million, 1/1,000,000, 0.000,001, and 0.000,1%
‰, parts per thousand:
Ratio between two values. These following are all the same: 1 ‰. one in one thousand, 1/1,000, 0.001, and 0.1%
refclock:
Reference clock, a local GPS module or other local source of time.
remote clock:
Any clock reached over the network, LAN or WAN. Also called a peer or server.
time offset:
The difference between the ntpd calculated time and the local system clock's time. Also called phase offset.
σ, sigma:
Sigma denotes the standard deviation (SD) and is centered on the arithmetic mean of the data set. The SD is simply the square root of the variance of the data set. Two sigma is simply twice the standard deviation. Three sigma is three times sigma. Smaller is better.
The formula for sigma is: "σ = √[ ∑(xi-mu)^2 / N ]". Where xi denotes the data points and N is the number of data points.
skewness, Skew:
The skewness of a random variable X is the third standardized moment and is a dimension-less ratio. ntpviz uses the Pearson's moment coefficient of skewness. Wikipedia describes it best: "The qualitative interpretation of the skew is complicated and unintuitive."
A normal distribution has a skewness of zero.
upstream clock:
Any server or reference clock used as a source of time.
µs, us, microsecond:
One millionth of a second, also one thousandth of a millisecond, 0.000,001 seconds, and 1e-6 seconds.



This page autogenerated by ntpviz, part of the NTPsec project
html 5    Valid CSS!
