NTPsec

A-ntpsec-6-hour-stats

Report generated: Mon Mar 31 21:05:26 2025 UTC
Start Time: Mon Mar 31 15:05:25 2025 UTC
End Time: Mon Mar 31 21:05:25 2025 UTC
Report published: Mon Mar 31 02:05:32 PM 2025 PDT
Report Period: 0.2 days

Local Clock Time/Frequency Offsets

local offset plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local Clock Time Offset -2.813 -1.689 -0.991 0.147 1.070 1.501 2.444 2.061 3.190 0.643 0.106 µs -3.528 9.879
Local Clock Frequency Offset -441.711 -440.048 -434.006 -368.698 -307.709 -303.192 -302.460 126.297 136.856 41.284 -368.718 ppb -1009 1.032e+04

The time and frequency offsets between the ntpd calculated time and the local system clock. Showing frequency offset (red, in parts per million, scale on right) and the time offset (blue, in μs, scale on left). Quick changes in time offset will lead to larger frequency offsets.

These are fields 3 (time) and 4 (frequency) from the loopstats log file.



Local RMS Time Jitter

local jitter plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local RMS Time Jitter 0.413 0.495 0.559 0.802 1.187 1.418 1.727 0.628 0.923 0.198 0.830 µs 42.6 176.5

The RMS Jitter of the local clock offset. In other words, how fast the local clock offset is changing.

Lower is better. An ideal system would be a horizontal line at 0μs.

RMS jitter is field 5 in the loopstats log file.



Local RMS Frequency Jitter

local stability plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local RMS Frequency Jitter 154.000 182.000 213.000 302.000 443.000 512.000 593.000 230.000 330.000 71.081 310.950 10e-12 49.19 209.9

The RMS Frequency Jitter (aka wander) of the local clock's frequency. In other words, how fast the local clock changes frequency.

Lower is better. An ideal clock would be a horizontal line at 0ppm.

RMS Frequency Jitter is field 6 in the loopstats log file.



Local Clock Time Offset Histogram

local offset histogram plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local Clock Offset -2.813 -1.689 -0.991 0.147 1.070 1.501 2.444 2.061 3.190 0.643 0.106 µs -3.528 9.879

The clock offsets of the local clock as a histogram.

The Local Clock Offset is field 3 from the loopstats log file.



Local Temperatures

local temps plot

Local temperatures. These will be site-specific depending upon what temperature sensors you collect data from. Temperature changes affect the local clock crystal frequency and stability. The math of how temperature changes frequency is complex, and also depends on crystal aging. So there is no easy way to correct for it in software. This is the single most important component of frequency drift.

The Local Temperatures are from field 3 from the tempstats log file.



Local Frequency/Temp

local freq temps plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local Clock Frequency Offset -441.711 -440.048 -434.006 -368.698 -307.709 -303.192 -302.460 126.297 136.856 41.284 -368.718 ppb -1009 1.032e+04
Temp ZONE0 45.084 45.084 45.084 46.160 46.698 47.236 47.236 1.614 2.152 0.496 45.929 °C

The frequency offsets and temperatures. Showing frequency offset (red, in parts per million, scale on right) and the temperatures.

These are field 4 (frequency) from the loopstats log file, and field 3 from the tempstats log file.



Local GPS

local gps plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
nSats 8.000 8.000 8.000 10.000 12.000 12.000 12.000 4.000 4.000 1.054 9.854 nSat 607.8 5295
TDOP 0.570 0.590 0.650 0.830 1.390 1.420 1.430 0.740 0.830 0.197 0.870 51.23 226.8

Local GPS. The Time Dilution of Precision (TDOP) is plotted in blue. The number of visible satellites (nSat) is plotted in red.

TDOP is field 3, and nSats is field 4, from the gpsd log file. The gpsd log file is created by the ntploggps program.

TDOP is a dimensionless error factor. Smaller numbers are better. TDOP ranges from 1 (ideal), 2 to 5 (good), to greater than 20 (poor). Some GNSS receivers report TDOP less than one which is theoretically impossible.



Server Offsets

peer offsets plot

The offset of all refclocks and servers. This can be useful to see if offset changes are happening in a single clock or all clocks together.

Clock Offset is field 5 in the peerstats log file.



Server Offset 15.204.249.252

peer offset 15.204.249.252 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 15.204.249.252 3.751 3.751 4.169 4.700 5.277 5.501 5.501 1.108 1.751 0.346 4.735 ms 2074 2.677e+04

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 162.159.200.1

peer offset 162.159.200.1 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 162.159.200.1 1.233 1.233 1.366 1.874 2.284 3.896 3.896 0.918 2.663 0.422 1.893 ms 55.31 269

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 162.159.200.123

peer offset 162.159.200.123 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 162.159.200.123 0.229 0.229 0.814 1.167 2.721 3.253 3.253 1.907 3.024 0.539 1.332 ms 9.129 33.29

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 169.229.128.134

peer offset 169.229.128.134 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 169.229.128.134 1.207 1.207 1.450 1.693 2.052 3.559 3.559 0.602 2.352 0.275 1.730 ms 167.3 1060

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 173.11.101.155

peer offset 173.11.101.155 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 173.11.101.155 -1.895 -1.895 -1.341 0.317 2.728 3.404 3.404 4.069 5.299 1.242 0.393 ms -1.895 4.406

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 192.12.19.20

peer offset 192.12.19.20 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 192.12.19.20 0.021 0.021 2.046 2.555 3.146 3.688 3.688 1.100 3.666 0.429 2.517 ms 127.5 672.6

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 50.116.42.84

peer offset 50.116.42.84 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 50.116.42.84 1.781 1.781 2.174 3.227 5.124 5.399 5.399 2.951 3.617 0.729 3.259 ms 53.17 233.8

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 52.10.183.132

peer offset 52.10.183.132 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 52.10.183.132 3.117 3.117 3.259 3.868 4.617 4.809 4.809 1.358 1.692 0.408 3.874 ms 638.2 5642

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 64.142.122.36

peer offset 64.142.122.36 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 64.142.122.36 0.513 0.513 1.311 1.633 1.872 3.771 3.771 0.560 3.257 0.359 1.635 ms 58.53 294.6

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset 66.220.9.122

peer offset 66.220.9.122 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset 66.220.9.122 0.702 0.702 1.642 2.137 2.327 2.363 2.363 0.685 1.661 0.256 2.091 ms 385 2866

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset SHM(0)

peer offset SHM(0) plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset SHM(0) -100.862 -100.033 -99.284 -96.886 -95.476 -95.017 -94.640 3.808 5.016 1.204 -97.169 ms -5.451e+05 4.454e+07

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Offset SHM(1)

peer offset SHM(1) plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Offset SHM(1) -2.814 -1.690 -0.992 0.148 1.071 1.502 2.445 2.063 3.192 0.643 0.106 µs -3.528 9.871

The offset of a server in seconds. This is useful to see how the measured offset is behaving.

The chart also plots offset±rtt, where rtt is the round trip time to the server. NTP can not really know the offset of a remote chimer, NTP computes it by subtracting rtt/2 from the offset. Plotting the offset±rtt reverses this calculation to more easily see the effects of rtt changes.

Closer to 0s is better. An ideal system would be a horizontal line at 0s. Typical 90% ranges may be: local LAN server 80µs; 90% ranges for WAN server may be 4ms and much larger.

Clock Offset is field 5 in the peerstats log file. The Round Trip Time (rtt) is field 6 in the peerstats log file.



Server Jitters

peer jitters plot

The RMS Jitter of all refclocks and servers. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 15.204.249.252

peer jitter 15.204.249.252 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 15.204.249.252 0.182 0.182 1.117 1.842 5.616 13.687 13.687 4.499 13.505 2.094 2.396 ms 4.625 24.88

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 162.159.200.1

peer jitter 162.159.200.1 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 162.159.200.1 1.009 1.009 1.087 1.773 3.372 3.482 3.482 2.286 2.473 0.637 1.938 ms 15.43 51.6

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 162.159.200.123

peer jitter 162.159.200.123 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 162.159.200.123 0.782 0.782 0.795 1.589 9.772 10.020 10.020 8.977 9.238 2.185 2.428 ms 2.6 9.092

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 169.229.128.134

peer jitter 169.229.128.134 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 169.229.128.134 0.173 0.173 0.700 1.986 3.236 3.637 3.637 2.535 3.465 0.836 1.953 ms 6.374 15.84

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 173.11.101.155

peer jitter 173.11.101.155 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 173.11.101.155 1.167 1.167 1.809 3.508 6.527 10.565 10.565 4.718 9.398 1.609 3.731 ms 8.027 30.79

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 192.12.19.20

peer jitter 192.12.19.20 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 192.12.19.20 0.178 0.178 0.758 1.514 3.374 14.676 14.676 2.616 14.498 2.345 1.926 ms 4.383 23.61

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 50.116.42.84

peer jitter 50.116.42.84 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 50.116.42.84 0.352 0.352 0.582 1.916 20.312 24.494 24.494 19.731 24.142 4.741 3.077 ms 2.653 11.49

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 52.10.183.132

peer jitter 52.10.183.132 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 52.10.183.132 0.713 0.713 0.967 1.782 14.945 17.631 17.631 13.978 16.918 3.375 2.608 ms 2.869 11.59

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 64.142.122.36

peer jitter 64.142.122.36 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 64.142.122.36 0.177 0.177 0.690 1.653 6.903 21.045 21.045 6.214 20.868 2.904 2.464 ms 3.538 20.22

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter 66.220.9.122

peer jitter 66.220.9.122 plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter 66.220.9.122 0.133 0.133 0.202 1.259 3.124 10.333 10.333 2.922 10.200 1.378 1.548 ms 4.228 26.7

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter SHM(0)

peer jitter SHM(0) plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter SHM(0) 0.041 0.079 0.109 0.275 0.938 1.256 2.432 0.829 1.177 0.278 0.372 ms 2.753 9.802

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Server Jitter SHM(1)

peer jitter SHM(1) plot

Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Server Jitter SHM(1) 0.189 0.308 0.406 0.769 1.566 2.063 2.856 1.160 1.755 0.368 0.850 µs 7.54 26.04

The RMS Jitter of a server. Jitter is the current estimated dispersion, in other words the variation in offset between samples.

Closer to 0s is better. An ideal system would be a horizontal line at 0s.

RMS Jitter is field 8 in the peerstats log file.



Summary


Percentiles...... Ranges...... Skew- Kurt-
Name Min1%5%50%95% 99%Max   90%98%StdDev  MeanUnits nessosis
Local Clock Frequency Offset -441.711 -440.048 -434.006 -368.698 -307.709 -303.192 -302.460 126.297 136.856 41.284 -368.718 ppb -1009 1.032e+04
Local Clock Time Offset -2.813 -1.689 -0.991 0.147 1.070 1.501 2.444 2.061 3.190 0.643 0.106 µs -3.528 9.879
Local RMS Frequency Jitter 154.000 182.000 213.000 302.000 443.000 512.000 593.000 230.000 330.000 71.081 310.950 10e-12 49.19 209.9
Local RMS Time Jitter 0.413 0.495 0.559 0.802 1.187 1.418 1.727 0.628 0.923 0.198 0.830 µs 42.6 176.5
Server Jitter 15.204.249.252 0.182 0.182 1.117 1.842 5.616 13.687 13.687 4.499 13.505 2.094 2.396 ms 4.625 24.88
Server Jitter 162.159.200.1 1.009 1.009 1.087 1.773 3.372 3.482 3.482 2.286 2.473 0.637 1.938 ms 15.43 51.6
Server Jitter 162.159.200.123 0.782 0.782 0.795 1.589 9.772 10.020 10.020 8.977 9.238 2.185 2.428 ms 2.6 9.092
Server Jitter 169.229.128.134 0.173 0.173 0.700 1.986 3.236 3.637 3.637 2.535 3.465 0.836 1.953 ms 6.374 15.84
Server Jitter 173.11.101.155 1.167 1.167 1.809 3.508 6.527 10.565 10.565 4.718 9.398 1.609 3.731 ms 8.027 30.79
Server Jitter 192.12.19.20 0.178 0.178 0.758 1.514 3.374 14.676 14.676 2.616 14.498 2.345 1.926 ms 4.383 23.61
Server Jitter 50.116.42.84 0.352 0.352 0.582 1.916 20.312 24.494 24.494 19.731 24.142 4.741 3.077 ms 2.653 11.49
Server Jitter 52.10.183.132 0.713 0.713 0.967 1.782 14.945 17.631 17.631 13.978 16.918 3.375 2.608 ms 2.869 11.59
Server Jitter 64.142.122.36 0.177 0.177 0.690 1.653 6.903 21.045 21.045 6.214 20.868 2.904 2.464 ms 3.538 20.22
Server Jitter 66.220.9.122 0.133 0.133 0.202 1.259 3.124 10.333 10.333 2.922 10.200 1.378 1.548 ms 4.228 26.7
Server Jitter SHM(0) 0.041 0.079 0.109 0.275 0.938 1.256 2.432 0.829 1.177 0.278 0.372 ms 2.753 9.802
Server Jitter SHM(1) 0.189 0.308 0.406 0.769 1.566 2.063 2.856 1.160 1.755 0.368 0.850 µs 7.54 26.04
Server Offset 15.204.249.252 3.751 3.751 4.169 4.700 5.277 5.501 5.501 1.108 1.751 0.346 4.735 ms 2074 2.677e+04
Server Offset 162.159.200.1 1.233 1.233 1.366 1.874 2.284 3.896 3.896 0.918 2.663 0.422 1.893 ms 55.31 269
Server Offset 162.159.200.123 0.229 0.229 0.814 1.167 2.721 3.253 3.253 1.907 3.024 0.539 1.332 ms 9.129 33.29
Server Offset 169.229.128.134 1.207 1.207 1.450 1.693 2.052 3.559 3.559 0.602 2.352 0.275 1.730 ms 167.3 1060
Server Offset 173.11.101.155 -1.895 -1.895 -1.341 0.317 2.728 3.404 3.404 4.069 5.299 1.242 0.393 ms -1.895 4.406
Server Offset 192.12.19.20 0.021 0.021 2.046 2.555 3.146 3.688 3.688 1.100 3.666 0.429 2.517 ms 127.5 672.6
Server Offset 50.116.42.84 1.781 1.781 2.174 3.227 5.124 5.399 5.399 2.951 3.617 0.729 3.259 ms 53.17 233.8
Server Offset 52.10.183.132 3.117 3.117 3.259 3.868 4.617 4.809 4.809 1.358 1.692 0.408 3.874 ms 638.2 5642
Server Offset 64.142.122.36 0.513 0.513 1.311 1.633 1.872 3.771 3.771 0.560 3.257 0.359 1.635 ms 58.53 294.6
Server Offset 66.220.9.122 0.702 0.702 1.642 2.137 2.327 2.363 2.363 0.685 1.661 0.256 2.091 ms 385 2866
Server Offset SHM(0) -100.862 -100.033 -99.284 -96.886 -95.476 -95.017 -94.640 3.808 5.016 1.204 -97.169 ms -5.451e+05 4.454e+07
Server Offset SHM(1) -2.814 -1.690 -0.992 0.148 1.071 1.502 2.445 2.063 3.192 0.643 0.106 µs -3.528 9.871
TDOP 0.570 0.590 0.650 0.830 1.390 1.420 1.430 0.740 0.830 0.197 0.870 51.23 226.8
Temp ZONE0 45.084 45.084 45.084 46.160 46.698 47.236 47.236 1.614 2.152 0.496 45.929 °C
nSats 8.000 8.000 8.000 10.000 12.000 12.000 12.000 4.000 4.000 1.054 9.854 nSat 607.8 5295
Summary as CSV file


Glossary:

frequency offset:
The difference between the ntpd calculated frequency and the local system clock frequency (usually in parts per million, ppm)
jitter, dispersion:
The short term change in a value. NTP measures Local Time Jitter, Refclock Jitter, and Server Jitter in seconds. Local Frequency Jitter is in ppm or ppb.
kurtosis, Kurt:
The kurtosis of a random variable X is the fourth standardized moment and is a dimension-less ratio. ntpviz uses the Pearson's moment coefficient of kurtosis. A normal distribution has a kurtosis of three. NIST describes a kurtosis over three as "heavy tailed" and one under three as "light tailed".
ms, millisecond:
One thousandth of a second = 0.001 seconds, 1e-3 seconds
mu, mean:
The arithmetic mean: the sum of all the values divided by the number of values. The formula for mu is: "mu = (∑xi) / N". Where xi denotes the data points and N is the number of data points.
ns, nanosecond:
One billionth of a second, also one thousandth of a microsecond, 0.000000001 seconds and 1e-9 seconds.
percentile:
The value below which a given percentage of values fall.
ppb, parts per billion:
Ratio between two values. These following are all the same: 1 ppb, one in one billion, 1/1,000,000,000, 0.000,000,001, 1e-9 and 0.000,000,1%
ppm, parts per million:
Ratio between two values. These following are all the same: 1 ppm, one in one million, 1/1,000,000, 0.000,001, and 0.000,1%
‰, parts per thousand:
Ratio between two values. These following are all the same: 1 ‰. one in one thousand, 1/1,000, 0.001, and 0.1%
refclock:
Reference clock, a local GPS module or other local source of time.
remote clock:
Any clock reached over the network, LAN or WAN. Also called a peer or server.
time offset:
The difference between the ntpd calculated time and the local system clock's time. Also called phase offset.
σ, sigma:
Sigma denotes the standard deviation (SD) and is centered on the arithmetic mean of the data set. The SD is simply the square root of the variance of the data set. Two sigma is simply twice the standard deviation. Three sigma is three times sigma. Smaller is better.
The formula for sigma is: "σ = √[ ∑(xi-mu)^2 / N ]". Where xi denotes the data points and N is the number of data points.
skewness, Skew:
The skewness of a random variable X is the third standardized moment and is a dimension-less ratio. ntpviz uses the Pearson's moment coefficient of skewness. Wikipedia describes it best: "The qualitative interpretation of the skew is complicated and unintuitive."
A normal distribution has a skewness of zero.
upstream clock:
Any server or reference clock used as a source of time.
µs, us, microsecond:
One millionth of a second, also one thousandth of a millisecond, 0.000,001 seconds, and 1e-6 seconds.



This page autogenerated by ntpviz, part of the NTPsec project
html 5    Valid CSS!
